All navigation buoys are successfully being used to demarcate a variety of marine and coastal areas, such as waterways, marinas, rivers, port entrances, ocean and offshore locations.
Our ZAZ steel buoys are of steel construction and with excellent stability characteristics. All ZAZ Marine Steel buoys are made in accordance with IALA guidelines.
They are characterized by their high shock resistance and stability. Metallic parts of the buoys (superstructure and tail) are made from hot-dip galvanized steel, and designed to provide a long service life under harsh marine conditions. They can be customized under client’s request, as well as to be made from stainless steel or marine aluminium.
Brand: ZAZ
Diameter: 1200mm
Total height: 2400mm
Thickness of plate: 6mm
Navigation draft:>1000mm
Total weight: 400kg
Wind resistance: >45m/s
Temperature range: -40~50℃
Anchor Chain diameter: ¢17.5mm
Sinker weight: 500kg~1000kg
Focal height: >3000mm
The height of freeboard: >700mm
Reserve buoyancy: 500kg
